18 : Motor 1/50HP Fan & Blower 3.3" Dia. 1550 RPM CCWle Rotation115V Open Air Over
A.O. Smith 18 Open Ventilated Fan & Blower Duty Motor
Applications Hvac, Refrigeration and other applications needing these specifications.
Use with some Fedders, McQuay, Bohn, Witt Coil, American Standard, Miami Carey, Duotherm, Coleman, Phil Rich, Chrysler and others.
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 3.3 |
| Frame: | 3.3 |
| HP: | 1/50 |
| Volts: | 115 |
| Frequency: | 60Hz |
| Amps: | 0.75 |
| Phase: | 1 |
| RPM: | 1550 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CCW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Duty: | Continuous Air Over |
| Shaft: Diameter x Length (Inches): | 1/4 x 2.5 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 2.5 |
| Thermal Protection: | Automatic |
| Service Factor: | 1.00 |
| Mounting: | Stud Front & Back |
| Wiring: | Leads |
| Volts (V): | 115 |
| Amperage: | 0.75 |
| Shaft Dimensions (in): | 1/4 x 2.5 |
| Mounting Type: | Stud Front & Back |
| Clearance: | Yes |
Replaces Old Numbers: 61A5S-A2442, 663001001034, 6A51-A663, 6A5N-A2498, 7163-1477, 7163-6053, 7163-7111, 80093, 80913, 82120, D120, D603, F-3334, S196-4-1
Fits Models: RS6750XVN2 , RS6750XVW2 , RS676PXV1
