30-FFI10HBX : Universal R134a Refrigeration Compressor, 1/3hp, Low/Med/High Back Pressure
Compare at: $ 532.82
You Save: $ 48.44
SHIPS: IMMEDIATELY
Embraco Universal FFI10HBX R134a Refrigeration Compressor. Low, Medium & High Back Pressure. 1/3 Nominal Motor HP. For use with refrigerators, ice makers, frozen food cabinets, frozen food display cases, display windows, etc.
Replaces Tecumseh AEA4440YXA and AEA3440YXA.
Motor: Captive Start Inductive Run (CSIR)
Evaporating Temperatures: -10°F to 45°F
Product Downloads
Wiring Diagram
Product Specifications
| Product Specifications | |
|---|---|
| HP (Nominal): | 1/3 |
| Volts: | 120 |
| BTU Capacity LBP & MBP: | 1065 |
| BTU Capacity HBP: | 4400 |
| Required Refrigerant : | R134a |
| Starting Torque: | High |
| Motor Type: | CSIR |
| Locked Rotor Amps (LRA): | 35.0 |
| Horsepower (HP): | 1/3 |
| Volts (V): | 120 |
| BTU Capacity LBP & MBP: | 1065 |
| Has 360 Photos: | Yes |
| Skill Level: |  |
Replaces Old Numbers: 30-FF10HBK, 777980047126, EGS90HLP, FF10HBK, FF10HBX, FFI10HBX1, TJFFI10HBX
