O6-R213 : Rotom 1/25 HP Condensor Fan & Electric Heater Motor 3.3" Dia. 1550 RPM, 115V, Trane, Chromalox, Lincoln
Compare at: $ 174.15
You Save: $ 15.83
SHIPS: IMMEDIATELY
Rotom 06-R213 Electric Wall Heater, Condenser Fan & General Replacement Motor. 3.3" Diameter.
Application Wall Heaters & Others applications using a motor with these specifications.
Replaces SM213, SM302, 76213, SS213
Use with Trane, Chromalox, Caloritech & Lincoln Units.
Product Downloads
Product Specifications
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 3.3 |
| HP: | 1/25 |
| Volts: | 115 |
| Amps: | 1.40 |
| RPM: | 1550 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CCW |
| Bearing: | Sleeve |
| Enclosure: | Totally Enclosed |
| Shaft: Diameter x Length (Inches): | 5/16 x 1.7 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 3.1 |
| Mounting: | Triangular Bracket |
| Frame: | 3.3 |
| Frequency: | 50/60Hz |
| Phase: | 1 |
| Duty: | Continuous Air Over |
| Thermal Protection: | Automatic |
| Service Factor: | 1.00 |
| Wiring: | Leads |
| Volts (V): | 115 |
| Amperage: | 1.40 |
| Shaft Dimensions (in): | 5/16 x 1.7 |
| Mounting Type: | Triangular Bracket |
| Rotation: | CCW |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 06-R213, 13-53-12-03, 13-54-12-01, 184804, 2818-510-810, 2818-511-004, 2818-511-008, 2818-511-203, 2818-511-204, 2818-513-012, 2818-541-005, 2818-541-010, 2818-541-011, 2818-541-016, 2818-541-206, 2818-541-207, 2818-541-211, 2818-541-214, 2828-531-203, 2828-531-207, 2828-541-203, 2868-511-016, 2868-511-020, 2868-513-002, 2868-513-003, 2868-513-006, 2868-513-007, 2868-513-008, 2868-513-011, 2868-513-014, 2868-513-034, 2868-513-041, 2868-513-044, 2868-513-045, 2868-513-046, 2868-513-048, 2868-513-049, 2868-513-059, 2868-513-075, 2868-513-077, 2868-513-088, 2868-513-091, 2868-513-092, 2868-513-148, 2868-513-149, 2868-813-001, 2882-410-506, 70200011, 71512513, 76213, 777980000909, 8214117219, AA2R5555, AA2R5555K, AK4L143A, B01NCWJDBH, D184F, E-091, R12CCW50EA, R213, SM213, SM-213, SM-302, SS213, UE-431, YPSM213
Fits Models: 23352052003 ,
