T1-R603 : Exhaust Fan Motor, C Frame, 1/125HP 2400RPM 115V, Nutone/Air King
Compare at: $ 77.04
You Save: $ 7.00
SHIPS: IMMEDIATELY
Exhaust Fan Motor
Use with Air Kink and other Exhaust Fans requiring these specifications.
Replaces Air King 2108370033
Replaces Nutone 81058, 81096, 81795,81826, 81827, 81993,81994, 82230
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Frame: | C Frame |
| HP: | 1/125 |
| Volts: | 115 |
| Amps: | 0.58 |
| RPM: | 2400 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Shaft: Diameter x Length (Inches): | 7/32 x 2.2 |
| Motor Type: | Shaded Pole |
| Body Stack ( Width Inches ): | 0.65 |
| Mounting: | Stud |
| Wiring: | Leads with Plug |
| Volts (V): | 115 |
| Amperage: | 0.58 |
| Shaft Dimensions (in): | 7/32 x 2.2 |
| Mounting Type: | Stud |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 15030010050, 184745, 21-08370-033, 2858-106-018, 2858-203-005, 2858-204-014, 2858-204-024, 2858-205-007, 2858-205-015, 2858-205-022, 2858-205-023, 2858-206-018, 2858-206-032, 2858-409-004, 777980003245, 81058, 81096, 81795, 81826, 81827, 81993, 81994, 86-SRYY-877E, B01N234ZV0, B01N4SK71C, R603
