T1-R617 : Rotom 1/285 HP Electric Heater Motor, 1900 RPM, 208/230V, Chromalox, Westcan, Dimplex
Compare at: $ 99.28
You Save: $ 9.03
SHIPS: IMMEDIATELY
Rotom R617 Electric Heater Motor
Applications Electric Heaters, Ventilators
Use with Chromalox, Westcan, Dimplex Heaters and other Applications requiring these specifications.
Replaces 04-290-004, 12657005, 12657004, SM607
Shaft C Ring Grooved.
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Frame: | C Frame |
| HP: | 1/285 |
| Volts: | 208/230 |
| Amps: | 0.22 |
| RPM: | 1900 |
| Speeds: | 1 |
| Rotation: | Reversible |
| Rotation: Opposite Shaft End: | CCW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Duty: | Air Over |
| Shaft: Diameter x Length (Inches): | 3/16 x 1.1 ( .181 x 1.1 ) |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 0.40 Stack |
| Mounting: | Studs Rear |
| Wiring: | Leads |
| Volts (V): | 208/230 |
| Amperage: | 0.22 |
| Shaft Dimensions (in): | 3/16 x 1.1 ( .181 x 1.1 ) |
| Mounting Type: | Studs Rear |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 04-290-004, 12657004, 12657-004, 12657005, 12657-005, 184805, 2858-103-015, 2858-103-022, 2858-103-024, 2858-103-030, 2858-103-031, 2858-103-036, 2858-103-038, 2858-103-039, 2858-103-044, 2858-103-045, 2858-103-046, 2858-104-042, 2858-104-044, 2858-105-053, 2858-108-017, 2858-205-012, 4290004, 5007T, 777980002620, B01MY9BG7Z, K-L82-288B, R617, SM607, SM-607
