UE-381 : A.O. Smith 1/10HP Fancoil/Air Conditioning Motor 5.0" Dia. 1075 RPM, 208/230V
Compare at: $ 526.32
You Save: $ 47.85
SHIPS:
USUALLY 1 TO 2 WEEKS DELIVERY A.O. Smith 381 Fancoil, Blower Motor.
Applications Fan Coils, Air Conditioners, PTAC Units, Blowers using these specifications.
Replaces U381 - 2946 - D292 - DB6506 - S89-785
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Rotation Double Shaft: Lead End: | CW |
| Frame: | 42 |
| HP: | 1/10-1/15-1/20 |
| Volts: | 208/230 |
| Frequency: | 60Hz |
| Amps: | .81-.56-.44 |
| Phase: | 1 |
| RPM: | 1075 |
| Speeds: | 3 |
| Bearing: | Sleeve |
| Body Diameter (Inches): | 5.0 |
| Enclosure: | Open |
| Duty: | Continuous Air Over |
| Shaft: Diameter x Length (Inches): | 1/2 x 10.63 & 1/2 x 10.63 |
| Motor Type: | Permanent Split Capacitor |
| Shaft Height (Inches): | 3.5 |
| Body Length (Inches): | 3.25 |
| Capacitor: | 5MFD 370 |
| Capacitor Included: | N |
| Thermal Protection: | Automatic |
| Ambient Temperature (Celsius): | 40 |
| Service Factor: | 1.00 |
| Mounting: | Resilient Base |
| Wiring: | Leads 36" Minimum |
| Volts (V): | 208/230 |
| Amperage: | .81-.56-.44 |
| Shaft Dimensions (in): | 1/2 x 10.63 & 1/2 x 10.63 |
| Shaft (in): | 3.5 |
| Ambient Temperature (C): | 40 |
| Mounting Type: | Resilient Base |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 292, 381, 381AOS, 400425, 70483, 7151-0156, 7176-0060, D1013, D292, D655, DB6502, R2381, S196-18-6, S196-41-1, S196-43-18, U381, UE381
