UE-48 : A.O. Smith 1/20 HP Direct Drive Fan & Blower Motor 4.3" Dia. 1050 RPM, 115V
SKU: UE-48
A.O. Smith 48 Direct Drive Fan & Blower Motor.
Applications Heating & Venting Fans, Blowers, Air Handlers, Condenser Fans, and Unit Heaters.
OEM replacement for Luxaire, Home, Lau, Taylor Freezer, Slirpy, Duotherm, Loren Cook, Lennox, Bohn, Wagner, Reznor, Lincoln, Miller, Hobart, Westinghouse, Intertherm, Jenn Air and similar applications.
Replaces 2901, 2902, 300174
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Body Diameter (Inches): | 4-5/16 |
| Frame: | 4.3 |
| HP: | 1/20 |
| Volts (V): | 115 |
| Volts: | 115 |
| Amperage: | 2.10 |
| Amps: | 2.10 |
| Frequency: | 60Hz |
| Phase: | 1 |
| RPM: | 1,050 |
| Rotation: | CCW |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CCW |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Duty: | Continuous Air Over |
| Shaft: Diameter x Length (Inches): | 3/8 x 2.5 |
| Shaft Dimensions (in): | 3/8 x 2.5 |
| Shaft (in): | 3/8 x 2.5 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 3.5 |
| Thermal Protection: | Automatic |
| Service Factor: | 1.00 |
| Mounting: | Stud |
| Mounting Type: | Stud |
| Body Length (In): | 3.5 |
| Wiring: | Leads |
| Weight Lbs.: | 6.0 |
| Weight (lbs): | 6.0 |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 48, 663001001645, 786674005984, CA3G635N, UE48
