UE-89 : A.O. Smith 1/10-1/70HP Fancoil/Air Conditioning Motor, 5.0" Dia. 1050 RPM, 115V
Compare at: $ 416.48
You Save: $ 37.86
SHIPS:
USUALLY 1 TO 2 WEEKS DELIVERY A.O. Smith 89 Air Conditioning Fan Coil Motor
Applications Fan coil units and other Dual blower units using these specifications.
Replaces 89, UE89
O.E.M. replacement for:Trane, Dunham-Bush, American Standard, Nesbitt, York, Fedders, Carrier, U.S.
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Bearing: | Sleeve |
| Frame: | 42 |
| HP: | 1/10, 1/20, 1/30, 1/40, 1/70 |
| Volts: | 115 |
| Frequency: | 60/50Hz |
| Amps: | 3.20, 2.30, 1.70, 1.40, 0.96 |
| Phase: | 1 |
| RPM: | 1050 |
| Speeds: | 5 |
| Rotation Double Shaft: Lead End: | CW |
| Body Diameter (Inches): | 5.0 |
| Enclosure: | Open |
| Duty: | Continuous Air Over |
| Shaft: Diameter x Length (Inches): | 1/2 x 10-11/16 & 1/2 x 10-11/16 |
| Motor Type: | Shaded Pole |
| Body Length (Inches): | 3.5 |
| Shaft Height (Inches): | 3-1/2 |
| Thermal Protection: | Automatic |
| Ambient Temperature (Celsius): | 40 |
| Mounting: | Resilient Base |
| Service Factor: | 1.00 |
| Wiring: | Leads |
| Rotation: | Double Shaft |
| Volts (V): | 115 |
| Amperage: | 3.20, 2.30, 1.70, 1.40, 0.96 |
| Shaft Dimensions (in): | 1/2 x 10-11/16 & 1/2 x 10-11/16 |
| Shaft (in): | 3-1/2 |
| Ambient Temperature (C): | 40 |
| Mounting Type: | Resilient Base |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 10889, 2089, 2751, 326P120, 400246, 40089, 4M038, 663001000884, 69549003590, 70089, 70113, 70500079, 7151-0187, 7151-2428, 840899108247, 89, BL6049, D1010, D1014, D289, D389, DA3D206N, DA3E681N#, DBL6406, HVA811, R2634, S196-161-15, S196-20-2, S196-43-12, S196-84-1, S2751, S2901, S2902, S88-301, UE89, X70500079
