XB90C : Broan Nutone ULTRA GREEN Single-Speed Exhaust Fan, 90 CFM
Broan Nutone ULTRA GREEN™ Bath Exhaust Fan. 90 CFM <0.3 Sones. Single-Speed Fan, Recognized as the Most Efficient of ENERGY STAR®.
We didn’t just change one thing to make installation faster—we changed everything. From our unique telescoping mounting frame that fits through retrofit drywall openings without a need for attic access to our easy-to-insert snap-in blower and housing, we’ve designed the ULTRA™ Series to be the fastest, easiest, most universal installation. Don’t let the uncertainty of what’s behind the drywall stand in your way. Take on any installation knowing that ULTRA™ Series Ventilation Fans and Fan/Lights will make it easier and faster—up to 60% faster in retrofit installations and up to 20% faster in new construction. Because you don’t make money by wasting time.
90 CFM at 0.1" SP
HVI certified, best-achievable <0.3 Sone level provides nearly silent operation
Installs up to 60% faster in retrofit applications and up to 20% faster in new construction
Energy saving DC Motor
Energy Star Certified
Product Downloads
Installation Instructions
Product Specifications
| Product Specifications | |
|---|---|
| CFM: | 90 |
| Duct Size (in): | 6" Round (6" to 4" Reduced Included) |
| Grille Finish: | White Polymeric |
| Grille Size (in): | 13" x 13-3/4" |
| Housing Height (in): | 7-5/8" |
| Housing Length (in): | 10-1/2" |
| Housing Width (in): | 11-3/8" |
| Sones: | &lt;0.3 |
| Warranty: | 3 Years |
| Minimum Construction Space (in): | 2" x 8" |
| Energy Star Certified: | Yes |
| Airflow (CFM): | 90 |
| Grill Dimensions (in): | 13" x 13-3/4" |
| Energy Star Qualified: | Yes |
| Amperage: | 0.10 |
| Clearance: | Yes |
| Collar Material: | Metal |
| Grille Dimensions (in): | 13" x 13-3/4" |
| Has 360 Photos: | Yes |
| Heater: | No |
| Hz: | 60 |
| Light: | No |
| Speed: | Single-Speed |
| Volts (V): | 120 |
| Watts (W): | 6.6 |
Replaces Old Numbers: XB90
