T834N1010 : Honeywell Home 24V Mercury-Free Thermostat, Heat/Cool, °C
Compare at: $ 89.09
You Save: $ 8.10
SHIPS: IMMEDIATELY
Honeywell Home T834N1010 24V, 7 C to 32 C, Mercury Free, Heat/Cool Thermostat. Application 1 Heat/1 Cool Conventional Systems and Heat Pumps with No Auxiliary Heat.
Features:
Integrated thermometer and temperature setting scale.
Precise Snap-action switch.
Mount directly on wall or outlet box.
Includes dealer logo pocket.
Product Downloads
Installation Instructions- English
| Product Specifications | |
|---|---|
| Switch Type: | Precision Snap Action |
| Dimensions (in.): | 4 3/4 in. high x 2 7/8 in. wide x 1 3/8 in. deep |
| Dimensions (mm): | 121 mm high x 73 mm wide x 35 mm deep |
| Electrical Ratings: | 20 to 30 Vac |
| Stages: | 1 Heat/1 Cool |
| Supply Voltage: | 20 to 30 Vac |
| Switch Positions (System): | HEAT-OFF-COOL |
| Switch Positions (Fan): | AUTO-ON |
| Sensor Element: | Bimetal |
| Accuracy (F): | ±2 F |
| Accuracy (C): | ± 1°C |
| Switching Action: | SPDT |
| Terminal Designations: | R, Rc, W, Y, G, O, B |
| Changeover: | Manual |
| Setting Temperature Range (C): | 7°C to 35°C |
| Cool Current: | 0.02 A to 1.0 A Running |
| Heat Current: | 0.02 A to 1.0 A Running |
| Dimensions (in): | 2-7/8" x 4-3/4" x 1-3/8" |
| Electrical Rating (amp): | 20 - 30 VAC |
| Switch Action: | SPDT |
| Colour: | White |
| Millivolt Compatible: | No |
| Mounting: | Vertical |
| Power Source: | Hardwired |
| System Off: | Yes |
| Temperature Scale: | Celsius |
| Thermometer: | Yes |
| Thermostat Type: | Heat & Cool |
| Volts (V): | 20 - 30 VAC |
Replaces Old Numbers: 085267094054, 085267271387, 213425, 213426, 62154, B01N3M95V4, L37-023, T812C1000, T822K1000, T834C1699, T834C2499, T834C2580
