US-R90030 : Rotom 1/25HP Fan & Blower Motor, 1550 RPM, 115V
Compare at: $ 151.20
You Save: $ 13.75
SHIPS: IMMEDIATELY
Rotom R90030 Fan & Blower Motor.
Use with Blowers, Exhaust Fans, Range Hoods, Air Conditioners Etc.
Replaces 30, 40030
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| HP: | 1/25 |
| Volts: | 115 |
| Amps: | 1.60 |
| RPM: | 1550 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CCW |
| Frequency: | 60Hz |
| Phase: | 1 |
| Duty: | Continuous Air Over |
| Thermal Protection: | Automatic |
| Service Factor: | 1.00 |
| Wiring: | Leads |
| Body Diameter (Inches): | 3.3 |
| Frame: | 3.3 |
| Bearing: | Sleeve |
| Enclosure: | Open |
| Shaft: Diameter x Length (Inches): | 5-16 x 2.62 |
| Body Length (Inches): | 2.77 |
| Motor Type: | Shaded Pole |
| Mounting: | Stud |
| Volts (V): | 115 |
| Amperage: | 1.60 |
| Shaft Dimensions (in): | 5-16 x 2.62 |
| Mounting Type: | Stud |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 30AOS, 41107, 61A3B-A3622, 6241, 663001001133, 6A10C-A2504, 7163-1458, 7163-2164, 7163-2734, 7163-3364, 7163-3693, 7163-4186, 7163-4388, 7163-4439, 7173-0099, 777980041421, 80391, 8213917502, 8213917503, B01N6S0HKP, D1152, D132, F-3506, JA2N191, JA2N191N, MC245, MC425, R356, U61A1C-A5131, U6A18-A1168, UE30, UE-30
