DP-1P30A24 : Definite Purpose Magnetic Contactor, 1 Pole 30A 24V, with Shunt
Compare at: $ 60.49
You Save: $ 5.50
SHIPS: IMMEDIATELY
Alltemp DP-1P30A24 Definite Purpose Magnetic Contactor. 30 Amp, 24 Vac, 1 Pole With Shunt. Termination Screw Type 50/60 Hz.
Furnas #45EG10AJA
Contactors are designed to establish or interrupt a power circuit. Definite purpose contactors unlike general purpose contactors are non-rebuildable electronic controls designed for specific applications with clearly defined operating conditions.
Features lug, spade terminals, and protective covers
Compact size
Universal galvanized mounting plates
ARI 780/790 standards
Brass/copper terminals
Quick connect and screw terminals on coil
cURus approved
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Poles: | 1.5 |
| Full Loaded Amps: | 30 |
| Coil Voltage 50/60: | 24 |
| Locked Rotor Amps (240V): | 180 |
| Locked Rotor Amps (480V): | 150 |
| Locked Rotor Amps (600V): | 120 |
| Resistive Amps: | 40 |
| Termination: | Screw Type |
| Has 360 Photos: | Yes |
Replaces Old Numbers: 100438-04, 10F73, 10F7301, 20394901, 20F72, 2427531000, 45EG10AJA, 46F40, 52M48, 52M4801, 61320, 65C69, 65C6901, 72L10, 72L1001, 777980044590, 84K73, 94-388, 95M55, B01N0BM05U, HC-13024, HN51KB024, HN51KC024
ALTERNATIVE PARTS
DP-1P30A24 - $54.99
