505 : Broan-Nutone 505 Vertical Discharge Exhaust Fan 8" 180 CFM
Compare at: $ 193.50
You Save: $ 17.59
SHIPS:
USUALLY 1 TO 3 WEEKS DELIVERY Broan Nutone Utility Vertical Discharge Bath Exhaust Fan. 180 CFM, 6.5 Sones.
Efficient, high-performance ventilation for laundry rooms, rec rooms & workshops. All feature powerful, permanently lubricated motor encased in rugged steel housing.
180 CFM 6.5 Sones.
Installs easily between ceiling joists.
Housing features built-in backdraft damper.
8-1/4” diameter and 7-15/16" high housing.
Fits 8” round duct.
cUL listed for kitchen use when used with optional aluminum filter model 99010042.
Product Downloads
Installation Instructions
Product Specifications
| Product Specifications | |
|---|---|
| Energy Star Qualified: | No |
| CFM: | 180 |
| Duct Size (in): | 8" Round |
| Grille Finish: | White Polymeric |
| Sones: | 6.5 |
| Warranty: | 1 Year |
| Grille Size (in): | 11-1/2" x 11-1/2" |
| Housing Height (in): | 7" |
| Housing Length (in): | 8-1/4" |
| Housing Width (in): | 8-1/4" |
| Energy Star Certified: | No |
| Airflow (CFM): | 180 |
| Grill Dimensions (in): | 11-1/2" x 11-1/2" |
| Amperage: | 1.50 |
| Fan Type: | Vertical Discharge |
| Grille Dimensions (in): | 11-1/2" x 11-1/2" |
| Has 360 Photos: | Yes |
| Hz: | 60 |
| RPM: | 1,975 |
| Volts (V): | 120 |
| Clearance: | Yes |
Replaces Old Numbers: 505N
