EC-9W115 : Elco Refrigerator Condenser Fan Motor, Multi-Mount, 9W, 1550RPM, 115V, Totally Enclosed
$47.96
Compare at: $ 52.76
You Save: $ 4.80
SKU: EC-9W115
SHIPS: IMMEDIATELY
Elco EC9W115 Condenser Fan Motor Multi-Mount.
Multi-Mount by Side Foot, 2-7/8" Bolt circle Tapped 3 Rear Holes, 3-3/4" Bolt circle for front Shroud.
Use with industrial and commercial condensing and evaporating units, ventilating units, freezers, wall-in and reach-in coolers, food beverage coolers and other fan duty applications.
Included: Nuts, Screws & Fan Blade Adapter
Long Life Lubricated Sintec Sleeve-Bearings
Product Downloads
Product Specifications
| Product Specifications | |
|---|---|
| Frame: | 33 |
| Watts: | 9 |
| Volts: | 115 |
| Amps: | 0.58 |
| Frequency: | 50/60Hz |
| RPM: | 1,550 |
| Speeds: | 1 |
| Rotation: Opposite Shaft End: | CW |
| Bearing: | Sleeve |
| Enclosure: | Totally Enclosed |
| Shaft: Diameter x Length (Inches): | Hubless |
| Duty: | Continuous Air-over |
| Motor Type: | Shaded Pole |
| Mounting: | Multi |
| Wiring: | 21" Leads W/#10 Ring Studs |
| Watts (W): | 9 |
| Volts (V): | 115 |
| Amperage: | 0.58 |
| Shaft Dimensions (in): | Hubless |
| Mounting Type: | Multi |
| Has 360 Photos: | Yes |
Similar Products Found in:
Refrigerator Parts & Service Products > Condenser Motors & Blades
Replaces Old Numbers: 777980040554, 9W115
