BU324WW : Broan® BU3 Series 24-inch Under-Cabinet Range Hood, 260 Max Blower CFM, White
This part has been replaced by Part # BU224WH
Key Features
- 2-speed at 210 Max Blower CFM pulls smoke and odors from air
- 2 incandescent lamps illuminate the cooktop
- Install as ducted or ductless recirculation to suit your needs
- Rotary control
Broan® BU3 Series 24-inch Under-Cabinet Range Hood, 260 Max Blower CFM, White. Air quality is a top concern for today's families, and the Broan series is the ideal solution. Perfect for the light cooking habits, the BU3 range hood models provides the quality you expect and the value you demand.
Features:
75 W bulb (not included) and direct lighting (2-level lighting)
Variable speed blower, HVI certified
Available in convenient 24" and 30" width
Contemporary styling in stainless steel and white
Four-way convertible range hood: horizontal, vertical, round and non-ducted
Use charcoal filter 41F for a non-ducted installation
Product Downloads
Product Specifications
Installation Instructions
| Product Specifications | |
|---|---|
| Amperage: | 2.5 |
| Built-In Timer : | No |
| Airflow (CFM): | 190 |
| Bulb Base Type : | E26 |
| Trim Colour: | White |
| Bulb Shape: | A19 |
| Depth (in): | 17-1/2" |
| Colour: | White |
| Control Type: | Rotary Switch |
| Duct Shape: | Rectangular |
| Heat Sensor: | No |
| Duct Direction : | Horizontal/Vertical |
| Electrical Rating (Hz): | 60 |
| Height (in): | 6" |
| Lighting Intensities: | 2 |
| Maximum Airflow (CFM): | 260 |
| Duct Size (in): | 3-1/4" x 10" |
| Non-Ducted Recirculation Capable: | Yes |
| HVI Certified: | Yes |
| Energy Star Qualified: | No |
| Sones (High Speed): | 7.5 |
| Light Source Max Wattage : | 75 |
| Lights Included : | No |
| Filter Type: | Aluminum |
| Minimum Height Above Cooktop (In) : | 18 |
| Volts (V): | 120 |
| Watts (W): | 300 |
| Lighting Intensity: | 2 Intensities |
| Lighting Type: | Incandescent |
| Non-Ducted Re-circulation Capable: | Yes with 41F Charcoal Filter |
| Optional Control: | No |
| Recirculation: | Yes |
| Sones: | 7 |
| Ventilation Speeds: | Variable |
| Warranty: | 1 Year |
| Width (cm): | 61 cm |
| Width (in): | 24" |
| Clearance: | Yes |
Replaces Old Numbers: BUS324WW, GP124WWN
