AE80 : Broan Flex™ Series InVent Exhaust Fan, 80 CFM, 0.7 Sone, Energy Star®
Key Features
- Quiet, energy efficient exhaust fan to help control air quality
- Powerful enough for rooms (including bathroom) up to 75 sq. ft.
- Easy to install new / replace existing product from the roomside
Broan Flex™ Series InVent Exhaust Fan, 80 CFM, 0.7 Sone, Energy Star®. Broan® AE80 Flex Series White 80 CFM Ceiling Exhaust Bath Fan, ENERGY STAR® offers easy, room side installation, with No Attic Access Required. Ceiling mounted ventilation fan features foldable mounting ears and EzDuct™ connector for easy installation. New duct damper technology provides a tighter seal, resulting in reduced warm and cold air backdrafts. This energy efficient fan operates at 80 CFM and a very quiet 0.7 Sones.
Features:
80 CFM, Effective ventilation to remove moisture and reduce the risk of mold or mildew in most full baths
0.7 Sone for Ultra quiet performance, you might not notice it's on
TrueSeal™ Damper technology reduces air leakage up to 50%*
EzDuct™ connector can be installed from the room side, with no attic access required
ENERGY STAR® certified for energy efficiency
UL listed for use over tub or shower when connected to a GFCI-protected branch circuit (ceiling mount only)
Powerful enough for rooms up to 75 sq. ft.
Corrosion resistant galvanized steel housing stands up to moisture
Optional galvanized steel duct expander for use with 6" ducting and optional installation brackets are sold separately
Product Downloads
Installation Instructions
Product Specifications
Product Specifications | |
---|---|
Airflow (CFM): | 80 |
Amperage: | 0.30 |
Collar Material: | Plastic |
Duct Size (in): | 4" Round (Non-metallic damper/duct connector included) |
Mounting Type: | Ceiling or Room Side |
Energy Star Qualified: | Yes |
Grille Dimensions (in): | 11-1/2" x 12" |
Grille Finish: | White Polymeric Plastic |
Heater: | No |
Housing Height (in): | 5 3/4 |
Housing Length (in): | 9 1/4 |
Housing Width (in): | 10 |
Hz: | 60 |
Light: | No |
Minimum Construction Space (in): | 2" x 6" |
Sones: | 0.7 |
Speed: | Single-Speed |
Volts (V): | 120 |
Warranty: | 3 Years |
Watts (W): | 26.9 |
Clearance: | Yes |
Replaces Old Numbers: 26715235278, AER80C, B016UQ2YQ0, QTRE090C
