36J54-214 : Emerson White-Rodgers Gas Valve, Natural Gas/LP, Fast Open, Two-Stage, 1/2" x 1/2", for Non-Piloted Intermittent Ignition Systems

$311.99
Qty:
SKU: 36J54-214
In-Stock     SHIPS: IMMEDIATELY
Image of 36J54-214
$311.99
Qty:

Compare at:   $ 343.19
You Save:   $ 31.20

SKU:   36J54-214
In-Stock     SHIPS: IMMEDIATELY

Emerson White-Rodgers Gas Valve 36J54-214, Natural Gas/LP, Fast Open, Two Stage, 1/2" x 1/2", for Non-Piloted Intermittent Ignition Systems. The versatile 36J series combination gas valves cover a wide range of applications. Designed for use with common ignition systems (HSI/DSI). The Control is Designed to meet Today’s Maximum Capacity, Smaller Size and High Efficiency Gas Systems.

Features:
Features:
Inlet and outlet screens.
Quiet redundant.
Built-in pressure tap.
Quick-connect terminals (1/4”).
Swing Radius: 2075"
Any Position Mounting
CSA Approved
Includes LP Conversion Kit and Reducer Bushing Kit

Product Downloads
Wiring Diagram
Installation Instructions
Sales Brochure
Product Specifications

  Product Specifications
  Ambient Temperature Range (C): -40 C to +79 C
  Ambient Temperature Range (F): -40 F to +175 F
  Body Pattern: Straight Through
  BTU/hr (LP): 226,800
  BTU/hr (LP)(High): 340,000
  BTU/hr (LP)(Low): 32,000
  BTU/hr (NG): 140,000
  BTU/hr (NG)(High): 210,000
  BTU/hr (NG)(Low): 20,000
  Electrical Connections: 1/4" Quick Connect
  Electrical Rating: 24 VAV
  Electrical Rating (amp): 0.43 amps
  Frequency: 50/60 Hz
  Ignition Type: Intermittent
  Inlet/Outlet Size (in): 1/2" x 1/2"
  Opening Characteristics: Fast Opening
  Pressure Ratings (kPa): 3.5 kPa
  Pressure Ratings (psi): 1/2 psi
  Pressure Regulator Adjustment Setting (psi)(LP): 6.0" - 12.0" WC
  Pressure Regulator Adjustment Setting (psi)(NG): 2.5" to 5.0" WC
  Pressure Tapping: Yes
  Regulator Adjustment Setting (psi)(LP)(Stage 1): 4.0" -10.0" WC
  Regulator Adjustment Setting (psi)(LP)(Stage 2): 6.0" -12.0" WC
  Regulator Adjustment Setting (psi)(NG)(Stage 1): 1.0" - 4.0" WC
  Regulator Adjustment Setting (psi)(NG)(Stage 2): 2.0" - 5.0"
  Type of Gas: Natural Gas/LP
  Has 360 Photos: Yes



Replaces Old Numbers:   0151F00000P, 025-35394-000, 025-35395-000, 025-38915-000, 1177542, 1179698, 1180955, 11J28-06894-001, 11J28-06894-002, 12654, 17624, 17625, 184032, 18654A, 18655A, 240006526, 30455, 30767, 341073, 36607, 36E54-205, 36E54-206, 36E54-207, 36E54-209, 36E54-210, 36E54-211, 36E54-212, 36E54-213, 36E54-215, 36E54-238, 36E54-239, 36E54-246, 36E54-250, 36E54-252, 36E96-1, 36E96-2, 36E96-215, 36E96-216, 36E96-217, 36E96-218, 36E96-219, 36E96-222, 36E96-223, 36E96-226, 36E96-228, 36E96-229, 36E96-232, 36E96-233, 36E96-235, 36E96-240, 36E96-244, 36E96-245, 36E96-247, 36E96-249, 36E96-250, 36E96-254, 36E96-256, 36E96-258, 36E96-259, 36E96-260, 36G54-201, 36G54-202, 36G54-208, 36G54-209, 36G54-214, 36G54-215, 36G54-216, 36G54-217, 36G54-218, 36G54-219, 36G54-22, 36G54-220, 36G54-222, 36G54-224, 36G54-226, 36G54-250, 36G54-251, 36G54-501, 36G54-508, 36J54-201, 36J54-202, 36J54-209, 36J54-216, 60-23490-04, 60-23490-05, 67143, 88J7601, 88J 7601, 88J-7601, 90034000, B1282618, BPF00547-1, C342086P01, C342087P01, C6476909, D670786P01, D674537P01, D674541P01, D674542P01, EF33CW187, EF33CW187A, HQ1006WR, R42380, TP-840A, TP-841A, VAL08027, VAL08055, VAL08237, X13120650010, X13120673010, X13120674010, X13120676010
